Air Dryer

Model: AW20 to AW1000

Working pressure: 5-16 bar

Capacity: 1.1/1.1/1/0.8 m3/min

Refrigerated dryers ensure dry compressed air, prolonging the life of equipment and ensuring excellent production quality. Efficient removal of water to avoid corrosion in compressed air networks and air tools. All in all, can reduce maintenance cost and improve overall level.

Flow Range: 20 to 1500 CFM.
Pressure range: ≤1.6 MPa (16 barg).
Maximum intake air temperature: 45^oC.
Maximum ambient temperature: 48^oC.
Cooling method: air-cooled.
Power supply: 220V/1Ph/50Hz (20 to 400 cfm) 415V/3Ph/50Hz (500 cfm & Above).
Refrigerant:R407c/R134a/R22a.
Rated working conditions: Working pressure 7 bar, intake air temperature 45^oC, ambient temperature 48^oC, dew point +3^oC (+1^oC to 4^oC)

Air Dryer Models:-

Model	Nominal Flow		Electric Supply (V/Ph/Hz)	Nominal Power KW	Air Connection	Dimensions In(mm)			Wt. Kg.
Model	cfm	m³/min	Electric Supply (V/Ph/Hz)	Nominal Power KW	Air Connection	L	W	H	Wt. Kg.
AW20	20	35	230/1/50	0.245	1/2 Inch	500	450	450	57
AW40	40	69	230/1/50	0.245	1/2 Inch	550	500	500	60
AW50	50	69	230/1/50	0.450	3/4 Inch	700	500	650	75
AW60	60	104	230/1/50	0.450	3/4 Inch	700	500	650	75
AW80	80	138	230/1/50	0.615	3/4 Inch	700	500	650	85
AW100	100	173	230/1/50	0.675	1 Inch	800	600	700	110
AW150	150	260	230/1/50	0.975	1½ Inch	850	650	700	120
AW200	200	346	230/1/50	0.975	1½ Inch	900	650	800	145
AW250	250	433	230/1/50	1.750	2 Inch	850	800	850	170
AW300	300	519	230/1/50	1.750	2 Inch	850	800	850	170
AW350	350	606	230/1/50	1.750	2 Inch	900	850	1000	180
AW400	400	692	413/3/50	2.275	2 Inch	900	850	1000	180
AW450	450	779	413/3/50	2.275	2 Inch	900	850	1000	190
AW500	500	865	413/3/50	2.365	3 Inch	900	850	1100	190
AW600	600	1038	415/3/50	3.3	3 Inch	1050	1000	1100	225
AW650	650	1125	415/3/50	3.3	3 Inch	1050	1000	1100	240
AW700	700	1211	415/3/50	6.6	3 Inch (F)	1500	1000	1100	-
AW800	800	1384	415/3/50	6.6	3 Inch (F)	1500	1000	1100	-
AW1000	1000	1730	415/3/50	7.1	4 Inch (F)	1800	1100	1100	-
AW1250	1250	2163	415/3/50	8.2	4 Inch (F)	1800	1100	1100	-
AW1500	1500	2595	415/3/50	10.7	4 Inch (F)	1900	1200	1400	-
